Water tank volume | L | 60 | 150 | 200 | 300 | 500 |
Shell material | / | Steel with powder coated | ||||
Shell thickness | mm | 0.5 | 0.6 | 0.6 | 0.6 | 0.7 |
Inner tank coating | / | Enamel | ||||
Inner tank material | / | SPCC*1.8 | SPCC*2.0 | SPCC*2.0 | SPCC*2.5 | SPCC*3.0 |
Inner tank diameter | / | ɸ340 | ɸ370 | ɸ410 | ɸ470 | ɸ600 |
Polyurethane thickness | / | 50 | 50 | 50 | 50 | 50 |
Using water water inlet/outlet conection | mm | G5/4" | G1/2" | G1/2" | G3/4" | G5/4" |
Circulation water inlet/outlet conection | mm | G5/4" | G3/4" | G3/4" | G3/4" | G5/4" |
Drain water conection | mm | G1/2" | G1/2" | G1/2" | G1/2" | G1/2" |
Magnesium rod | / | ɸ21*340*1pcs | ɸ26*360*2pcs | ɸ26*360*2pcs | ɸ26*460*2pcs | ɸ26*460*2pcs |
Design working pressure | Bar | 8 | 8 | 8 | 8 | 8 |
Testing pressure | Bar | 12 | 12 | 12 | 12 | 12 |
Unit dimension | mm | ɸ440*910 | ɸ470*1510 | ɸ510*1615 | ɸ570*1805 | ɸ700*1905 |
Packing dimension | mm | 510*510*910 | 540*540*1590 | 585*585*1690 | 645*645*1900 | 775*775*1990 |
Net Weight | kg | 31 | 50 | 58 | 85 | 135 |
Gross Weight | kg | 35 | 55 | 63 | 92 | 145 |
